Hautau Atrium HS

A complete line of tilt and slide fittings for windows and doors that covers ideally the modern architectural demands for big openings
but also the functional needs for sashes of big weight because of the use of security glass (bullet proof etc.)

The ATRIUM HS line includes fittings for all PVC profiles for doors and windows. A developed electrical system in very small dimensions secures the electrical function of the HS fittings.

Categories: , ,

The program HS of HAUTAU included full range of accessories for the series:

  • ALUMIL M300 Falcon / S 450 Premier Alutherm Inox
  • ALUSET T 650 / T 400
  • ALUMINCO 250
  • ALMACO Thermo 52
  • HYDRO Domal Slide PA 110
  • ELVIAL EL-6700 / EL-6800
  • EXALCO Albio 230 / Albio 235
  • EUROPA 10000
  • ETEM E 3000

Range of application

HS-330                 HS-440                      HS-200 slim

Sash width:  720-3235 mm     1310-3235 mm         650-2000 mm
Sash height: 1200-3300 mm       1200-3300 mm       1200-2700 mm
Sash weight:        330  Kg                     400  Kg                      200 Kg
Handle center: 37,5 mm                  37,5 mm                    27,5 mm

  HS-250 slim        HS-400 slim                 HS-120

Sash width:   650-2360 mm       1120-3235 mm         650-2000 mm
Sash height:     1200-2700 mm       1200-2700 mm       1200-2400 mm
Sash weight:            250  Kg                     400  Kg                      120 Kg
Handle center:     27,5  mm                  27,5 mm                    25,0 mm

Sketches of functional applications
